TASKalfa-4002i

  • Up to 40 pages per minute in A4 format
  • Standard print resolution of 1,200 x 1,200 dpi, 2 bit depth (equivalent of 4,800 x 1,200 dpi)
  • Flexible paper handling from A6 up to SRA3 and beyond for up to 7,150 sheets
  • Productive finishing options including a space-saving inner finisher
  • 4 GB RAM, 8 GB SSD + 320 GB HDD Memory and storage
  • Highly productive colour scanning
  • Comprehensive support for all state-of-the-art mobile communications
  • Long-life components providing efficiency and reliability, and less waste

Description

General type Monochrome multifunctional for A3 format
Technology KYOCERA Laser Monochrome, HyPASâ„¢ solution platform
Engine speed Up to 40/20 pages per minute A4/A3
Resolution 1200 x 1200 dpi, 2 bit depth for print quality of 4,800 dpi equivalent x 1,200 dpi
Warm-up time Approx. 17 seconds or less
Time to first copy Approx. 4.5 seconds or less
Dimensions (W x D x H) Main unit: 602 x 665 x 790 mm
Weight Main unit: Approx. 83 kg
Power consumption Printing: 610 W, Ready-mode: 40 W, Sleep-mode: 1.0 W or less
Power source AC 220 V – 240 V, 50/60 Гц
Noise (ISO 7779) Noise (sound pressure level ISO 7779/ISO 9296) Printing: 51.2 dB(A) LpA , Ready mode: 33.6 dB(A) LpA
Safety standards GS, TÃœV, CE – This unit is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. RoHS compatibility
General memory 4096 MB RAM , 8 GB SSD + 320 GB HDD

PAPER HANDLING

Input capacity 150-sheet multipurpose tray, 52 – 300 g/m² (Banner 135 – 165 g/m² ), A6R – SRA3 (320 x 450 mm), Tab paper (136 – 256 g/m² ), Banner max. 320 x 1,220 mm; 2x 500-sheet universal paper cassette, 52 – 300 g/m², upper cassette A6R up to A4R, lower cassette A6R up to SRA3
Max. input capacity with options 7,150 sheets A4
Duplex unit Duplex as standard supports A6R – SRA3 (320 x 450 mm), 64 – 256 g/m²
Max. output capacity Standard 500 sheets face-down, max. output capacity 4,300 sheets
Paper size 52–300 g/m², A6R-320 x 450 mm, Banner max. 320 x 1,220 mm
General paper handling All paper capacities quoted are based on paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions.

PRINT

Processor Freescale QorIQ T1024 (Dual Core) 1.2 GHz
Controller language PRESCRIBE
Emulations PCL6 (PCL-XL/PCL-5e), KPDL3 (PostScript 3 compatible), PDF Direct Print, XPS Direct Print and OpenXPS
Fonts 93 outline fonts (PCL ), 136 fonts (KPDL3), 8 fonts (Windows Vista), 1 Bitmap font, 45 types of one-dimensional barcodes plus two-dimensional barcode (PDF-417)
Features Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, Private Print, job storage and job management functionality
Protocol Mobile printing support: KYOCERA Mobile Print app for iOS and Android, AirPrint, Mopria, NFC, Direct Wi-Fi, Google Cloud Print
Applicable OS All current Windows operating systems, Mac OS X Version 10.8 or higher, UNIX LINUX, as well as other operating systems on request

COPY

Max. original size A3
Digital copy features Scan once copy many, electronic sort, 2-in-1 and 4-in-1 function, image repeat copy, page numbering, cover mode, booklet copy, interrupt copy, form overlay, stamp function and skip-blank-page function.
Exposure modes Auto, manual: 16 steps
Preset magnification ratios 5 Reductions/5 Enlargements
Zoom range 25 – 400 % in 1 % steps
Continuous copy 1 – 999
Image adjustments Text, Photo, Text + Photo, Map

SCAN

File type PDF (high compressive, encrypted, PDF/A), searchable PDF (option), JPEG, TIFF, XPS, OpenXPS
Original recognition Text, Photo, Text + Photo, optimised for OCR
Max. scan size A3, Banner up to 1,900 mm with optional Document processor
Scan functionalities Scan to e-mail, Scan to FTP, Scan to SMB, Scan to USB Host, Scan to box, Network TWAIN, WSD scan
Scan resolution 600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 400 dpi, 200 x 200 dpi, 200 x 100 dpi (24 bit)
Scan speed (A4, 300 dpi, Dual Scan with DP-7110) Colour: 180 images per minute, b/w: 180 image per minute,

FAX

Compatibility ITU-T Super G3
Modem speed Max. 33.6 kbps
Transmission speed Max. 3 seconds (JBIG)
Scanning density Normal: 200 x 100 dpi, Fine: 200 x 200 dpi, Superfine: 200 x 400 dpi, Ultrafine: 400 x 400 dpi, 600 x 600 dpi
Max. original size A3, Banner max. 1,600 mm
Compression method JBIG, MMR, MR, MH
Fax features Opt. Internet-fax, network faxing, rotate transmission, rotate reception, duplex fax reception, memory reception, mailbox, remote diagnostics, dual fax with second fax system 12

INTERFACES

Standard interface 4x USB 2.0 (Hi-Speed), USB Host 2.0, Fast Ethernet 10 BaseT/100 BaseTX/1000 BaseT, slot for optional print server, slot for optional SD-card, slot for optional Fax System
