Description
Maximum Tape Width (inches) | 2.4″ | |
Maximum Print Width (inches) | 2.3 | |
Maximum Label Length | 3 feet | |
Maximum Resolution (dpi) | 300 x 600 (Superfine mode) | |
Font Styles | True Type for Windows, Bitmap(5), Outline(3) | |
Memory for Transferred Data (number) | Yes (99 files or 2048 KB) | |
Symbols for Windows ( No. of Clip arts in P-touch Editor) | 1379 | |
Multiple Copies | Up to 9999 copies | |
Mirror Printing | Yes | |
Vertical Printing | Yes | |
Rotate Printing | Yes | |
Date/Time Stamp | PC Generated | |
Bar-codes Types | CODE39, CODE128, UCC/EAN-128(GS1-128), ITF(I-2/5), CODABAR(NW-7), UPC-A, UPC-E, EAN13(JAN13), ISBN-2, ISBN-5, POSTNET, EAN8, GS1 DataBar(RSS)(GS1 DataBar Omnidirectional,GS1 DataBar Truncated,GS1 DataBar Stacked,GS1 DataBar Stacked Omnidirectional,GS1 DataBar Limited,GS1 DataBar Expanded,GS1 DataBar Expanded Stacked), PDF417(Standard, Truncate, Micro), QR Code(Model 1, Model 2, Micro), Data Matrix (ECC200 Square, ECC200 Rectangular), MaxiCode (Model 2, Model 3, Model 4, Model 5) | |
Microsoft® Add-ins | Yes | |
Database File Compatibility | csv, txt, mdb, xls, Microsoft® SQL Server Database | |
Software | P-touch® Editor 5.0, P-touch® Address Book ver 1.1 for Windows®; P-touch® Editor 5.0 for Mac® | |
Networking | Built in | |
Interface | USB, RS-232C, 10/100 BASE-TX Wired Ethernet | |
Compatibility | PC & Mac OS® | |
Operating System | Windows® 2000, Windows® XP, Windows Vista®, Windows® 7; Windows® 8; Server 2003/Server 2008; Mac® OS X 10.8.x | |
Carton Contents | P-touch® Editor Software & Driver, USB Cable, Set-up & Operation Guide, AC Power Cord, DK Supplies Guide, Cleaning Sheet, Starter Rolls: DK-1201 Standard Address Labels (100 labels), DK-2205 2.4″ Continuous Length Paper Tape (25 ft.) | |
Housing Dimensions | 5.2 x 9.4 x 5.6 |
