Description
General type | B/W Multifunctional for A4 Format |
Technology | KYOCERA ECOSYS Laser |
Engine speed | Up to 35 pages per minute A4 |
Resolution | 1,200 dpi quality (1,800 x 600 dpi, print), 600 x 600 dpi, 256 greyscales (scan/copy) |
Warm-up time | 20 seconds or less |
Time to first print | Approx. 7 seconds or less |
Time to first copy | Approx. 6.9 seconds |
Weight | Main unit: Approx. 18 kg |
Power consumption | Copying/Printing: 439 W, Ready-mode: 65 W, Sleep-mode: 3.7Â W, Plug-in-off-mode: 0.3 W or less |
Power source | AC 220 ~ 240 V, 50/60 Hz |
Noise (ISO 7779 / ISO 9296) | Noise (sound pressure level ISO 7779 / ISO 9296) Copying/Printing: 51.3 dB(A) LpA, Half speed mode: 49 dB(A) lpA, Stand-by: 27.5 dB(A) LpA |
Safety standards | TÃœV/GS, CE – This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. |
General memory | Standard 512 MB, max. 1,536 MB |
Paper Handling
Input capacity | 50-sheet multi-purpose tray, 60-220 g/m², A4, A5, A6, B5, Letter, Legal, Folio, envelopes, Custom (70 x 148 to 216 x 356 mm); 250-sheet universal paper cassette, 60-120 g/m², A4, A5, A6, B5 Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm) |
Max. input capacity with options | 800 sheets |
Duplex unit | Duplex as standard supports 60–105 g/m² |
Output capacity | 150 sheets face-down |
Document processor | 50-sheet, Simplex scan 50–120 g/m², Duplex scan 50–110 g/m², A4, A5, B5, Letter, Legal, Custom (140 x 210 to 216 x 356 mm) |
Further information | All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by Kyocera under normal environmental conditions. |
Processor | PowerPC 465S / 667 MHz |
Controller language | PRESCRIBE IIe |
Emulations | PCL6 (5e/XL), KPDL 3 (PostScript 3-compatible), Line Printer, IBM Proprinter X24E, Epson LQ-850, PDF Direct Print Vers. 1.7, XPS Direct Print (requires memory expansion) |
Fonts | 93 outline fonts (PCL 6, HP-compatibile) + 8 (Windows Vista), 101 (KPDL3) 1 bitmap font, 45 types of one-dimensional barcodes, plus 1 type of two-dimensional barcode (PDF-417) |
Integrated Accounting | 100 department codes |
Features | Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3 and Private Print, IPPS, HTTPS, POP over SSL, AirPrint, SMT over SSL, FTPover SSL, LDAP over SSL |
Applicable OS (Print) | All current Windows operating systems, Mac OS X Version 10.4 or higher, UNIX, LINUX, as well as other operating systems on request. |
Copy
Max. original size | A4 / Legal |
Digital features | Scan-once-copy-many, electronic sort, 2in1, 4in1, ID-card copy, job reserve, priority print, program, auto duplex copy, split copy, continuous scan, auto cassette change, copy density control |
Exposure modes | Auto, manual: 5 steps |
Preset magnification ratios | 7 Reductions/5 Enlargements |
Zoom range | 25 – 400 % in 1% steps |
Continuous copy | 1 – 999 |
Image adjustments | Text + Photo, Text, Photo |
Scan
Compression format | MMR/JPEG |
File type | TIFF, PDF, JPEG, XPS, PDF/A |
Scan features | Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi-send (e-mail, fax, SMB/FTP folder, print) at once |
Original recognition | Text, Photo, Text + Photo, for OCR |
Max. scan size | A4 / Legal |
Scan functionalities | Scan-to-e-mail, Scan-to-FTP (FTP over SSL), Scan-to-SMB, Scan to USB Host, TWAIN (USB), WSD (WIA) scan (USB) |
Scan resolution | 200, 300, 400, 600 dpi (256 greyscales) |
Scan speed | 35 ipm (300 dpi, A4, B/W); 14 ipm (300 dpi, A4, colour) |
Fax
Compatibility | ITU-T Super G3 |
Modem speed | Max. 33.6 kbps |
Scanning speed | 2.5 seconds |
Transmission speed | 3 seconds or less |
Max. original size | A4 / Legal |
Compression method | JBIG, MMR, MR, MH |
Fax features | Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast, memory reception |
Interfaces
Standard interface | USB 2.0 (Hi-Speed), USB Host (High Speed), 10 Base-T/100 Base-TX/1000 Base-T, slot for optional SD card |
WARRANTY
Warranty | 2-year warranty as standard. KYOCERA guarantees the drum and developer for 3 years or 100,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions. |
