Usage type Desktop
Display Backlit LCD
RAM 512 MB
USB interface SuperSpeed USB 3.0
Dimensions & weights
With carton 437 W x 296 D x 320 H (mm
With carton 7.2 kg
Without carton 316 W x 187 D x 183 H (mm)
Weight 4.7 kg
Energy Consumption
Operating 59 watts
Ready mode 19 watts
Off 0.3 watts
Sleep mode 1.6 watts
Sound pressure 55 dBA
Operating humidity 20% – 80%
Operating temperature 5℃ – 35℃
In the box
Others PDS Machine, AC Adapter, Power supply cord, USB 3.0 cable, Software DVD, QSG, Warranty
Media specification
Types and sizes Plain Paper, Business Card, Plastic Card (embossed up to 1.25mm)
Weights 28 to 400 gsm (multiple sheets)
ADF media sizes Paper (single sheet WxL): 51-218 x 54-5994mm, Paper (multiple sheets WxL): 51-218 x 54-356mm, Long Paper Scanning (single sheet WxL): 218 x 5994 mm, Plastic card (WxL): 51-55 x 70-95, Plastic card Thickness: 0.4-0.76mm
Operating systems & software
Software supplied – Mac DS Capture, NewSoft® Presto!®, PageManager 9®
Software supplied – Windows Button Manager V2, Nuance® Omnipage 18SE, DS Capture
2-Sided scan Yes
ADF 100
Scan to email, Image, OCR, File, FTP, Network, SharePoint, Application, Printer (software supplied)
Colour A4 scan speed 80 ppm
Greyscale 8 bit
ICA compatibility Yes
ISIS compatibility Yes
Multi feed detection Yes
Paper sensor Yes
SANE compatibility Yes
Scan resolution from ADF  600 x 600
