Description
General type | B/W Multifunctional for A3 format |
Technology | KYOCERA Laser Monochrome, HyPAS™ solution platform |
Engine speed | Up to 35/17 pages per minute A4/A3 |
Resolution | 600 x 600 dpi, Multi-bit technology for print quality of 9,600 dpi equivalent x 600 dpi |
Warm-up time | Approx. 18 seconds or less from power on |
Time to first copy | Approx. 3.6 seconds |
Dimensions (W x D x H) | Main Unit: 594 x 696 x 680 mm |
Weight | Main unit incl. toner: Approx. 58 kg |
Power consumption | Printing: 660 W, Stand-by: 120 W, Energy saving priority: 1.0 W or less |
Power source | AC 220 V ~ 240 V, 50/60 Hz |
Noise (ISO 7779) | Noise (sound pressure level ISO ****/ISO****) Printing/copying: 46.8 dB(A) LpA, Stand-by: 26.1 dB(A) LpA |
Safety standards | GS, TÜV, CE – This unit is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. RoHs compatibility |
General memory | Standard 2048 MB, 32 GB SSD + optional 320 GB HDD |
PAPER HANDLING
Input capacity | 100-sheet multi-purpose tray, 45–256 g/m², A6R–A3, 2 x 500-sheet universal paper cassette, 60–163 g/m², A5R–A3 |
Max. input capacity with options | 4,100 sheets A4 |
Duplex unit | Duplex as standard supports A5R–A3, 60–160 g/m² |
Max. output capacity | 250 sheets face-down, max. output capacity 3,200 sheets |
General paper handling | All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by Kyocera under normal environmental conditions. |
Processor | Freescale QorIQ T1024**** (Dual Core) 1.0 GHz |
Controller language | PRESCRIBE |
Emulations | PCL6 (PCL5c/PCL-XL), KPDL3 (PostScript 3 compatible), PDF Direct Print, XPS Direct Print |
Fonts | 93 outline fonts (PCL), 136 fonts (KPDL3), 8 fonts (Windows Vista), 1 Bitmap font, 45 types of onedimensional barcodes plus two-dimensional barcode (PDF-417) |
Features | Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, Private Print, job storage and job management functionality |
Applicable OS | All current Windows operating systems, Mac OS X Version 10.8 or higher, UNIX LINUX, as well as other operating systems on request. |
COPY
Max. original size | A3 |
Digital copy features | Scan-once-copy-many, electronic sort, 2in1 and 4in1 function, image repeat copy, page numbering, cover mode, booklet copy, interrupt copy, form overlay, margin shift, stamp function and skip blank page function |
Exposure modes | Auto, manual: 16 steps |
Preset magnification ratios | 5 Reductions/ 5 Enlargements |
Zoom range | 25 – 400 in 1% steps |
Continuous copy | 1 – 999 |
Image adjustments | Text, Text + Photo, Photo, Map |
SCAN
File type | PDF (high compression PDF), Searchable PDF (Option), TIFF, JPEG, XPS |
Original recognition | Text, Photo, Text + Photo, optimised for OCR |
Max. scan size | A3, Banner up to 1,900 mm with optional Document Processor |
Scan functionalities | Scan-to-email, Scan-to-FTP, Scan-to-SMB, Scan-to-USB Host, Scan-to-box, Network TWAIN, WSD scan |
Scan resolution | 600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 400 dpi, 200 x 200 dpi, 200 x 100 dpi (24 bit) |
Scan speed | (A4, 300 dpi, Dual Scan with DP-7110) 160 originals per minute in b/w, 160 originals per minute in colour |
FAX
Compatibility | ITU-T Super G3 |
Modem speed | 33.6 kbps |
Transmission speed | Max. 3 seconds (JBIG) |
Scanning density | Normal: 200 x 100 dpi, Fine: 200 x 200 dpi, Superfine: 200 x 400 dpi, Ultrafine: 400 x 400 dpi, 600 x 600 dpi |
Max. original size | A3, Banner max. 1,600 mm |
Compression method | MH, MMR, MR, JBIG |
Fax features | Opt. Internet-fax, network faxing, rotate transmission, rotate reception, duplex fax reception, memory reception, mailbox, remote diagnostics, dual fax with second fax system 12 |
INTERFACES
Standard interface | USB 2.0 (Hi-Speed), USB Host 2.0, Fast Ethernet 10 BaseT/100 BaseTX/1,000 BaseT, slot for optional print server, slot for optional SD card, slot for optional Fax System 12 |
