Description
| Hardware | |
| Interface | – 1 *1000Mbps PoE port (Auto MDI/MDIX) |
| Button | – 1 * RST button |
| Power Supply | – IEEE 802.3af/at compliant PoE |
| LED Indicato | – 1 * SYSTEM LED (three colors) |
| Antenna | – 4 *Internal Antennas |
| Dimensions (L x W x H) | – 9.6 x 2.2 in. (245 x 55 mm) |
| Wireless | |
| Standards | – IEEE 802.11ac, |
| – IEEE 802.11a | |
| – IEEE 802.11b, | |
| – IEEE 802.11g, | |
| – IEEE 802.11n | |
| RF Frequency | – 2.4GHz/5GHz |
| Data Rate | – 5GHz: 866Mbps |
| – 2.4GHz: 300Mbps | |
| EIRP | – 2.4GHz < 20dBm |
| – 5GHz < 20dBm | |
| Wireless Security | – 64/128-bit WEP, WPA and WPA2 |
| Reception Sensitivity | -2.4G: 11b: < -81dBm |
| Â Â Â Â Â Â 11g: -68dBm | |
| Â Â Â Â Â Â 11n: HT20 < -65dBm, HT40 < -62dBm | |
| – 5G:Â 11a: -68dBm | |
| Â Â Â Â Â 11ac: -51dBm | |
| Â Â Â Â Â Â 11n: HT20 < -65dBm, HT40 < -62dBm | |
| Software | |
| Status | – System Status |
| Network | – LAN Setting |
| Operation Mode | – Bridge Mode |
| Wireless | – Basic Settings |
| Management | – Administrator Setting |
| – Time Setting | |
| – Upgrade Firmware | |
| – System Configuration | |
| – System Log | |
| – Reboot Schedule | |
| – Logout |
